4.Removethe2knobsandcurvedwashersthatsecure
therightbafetothemower(Figure28).
Figure28
1.Knob
3.Bafestudcomingthrough
themower
2.Curvedwasher
5.Removetherightbafeandlowerthegrassdeector
overthedischargeopeningasshowninFigure28and
Figure29.
Figure29
1.Rightbafe
3.Dischargeopening
2.Curvedwasherandknob
6.Installfastenersintotheholesinthetopofthemower
topreventyingdebris.
WARNING
Openholesinthemowerexposeyouand
otherstothrowndebriswhichcancause
severeinjury.
•Neveroperatethemowerwithouthardware
mountedinallholesinthemowerhousing.
•Installthehardwareinthemountingholes
whenyouremovethemulchingbafe.
7.Installtherightmowerblade;refertoRemovingthe
Blades(page44).
8.Liftupthegrassdeector.Install2bolts(5/16x3/4
inch)tothetwoholesalongthedeckcutout.
9.Installthecutoffbafetothemowerdeck(Figure30).
Note:Usethe2locknuts(5/16inch)tosecurethe
bafetothemowerdeck.
Note:Thecutoffbafewasshippedwiththemachine
asaloosepart.
G015321
1
2
3
Figure30
1.Bolt(5/16x3/4inch)3.Locknut(5/16inch)
2.Cutoffbafe
10.Torquethefastenersto7to9N-m(14to18ft-lb).
11.Lowerthegrassdeectoroverthedischargeopening.
Important:Ensurethatthemowerhasahinged
grassdeectorthatdispersesclippingstotheside
anddowntowardtheturf,whileinsidedischarge
mode.
