Toro 79391 - Setup

Setup
Loose Parts
Use the chart below to verify that all parts have been shipped.
Procedure Description
Qty .
Use
1
No parts required
–
Prepare the machine.
Bolt (3/8 x 1-1/4 inches)
4
Locknut (3/8 inch)
4
W eight mounting bracket, left
1
W eight mounting bracket, right 1
W ashers 4
W eight bracket 1
Bolt (3/8 x 1 inch)
2
Flat weight 1
Suitcase weight
1
2
Keyed cross bar 1
Install the weight.
Stabilizer bracket (For 2015 and newer
Models)
1
Carriage bolt (5/16 x 3/4 inch)
2
Locknut (5/16 inch)
4
Self-tapping screw (5/16 x 3/4 inch)
2
Bolt (5/16 x 1 inch)
2
Pivot frame
1
Hairpin cotter 2
Rod 2
W asher 2
3
Draw-bar decal 1
Install the attachment mount.
Latch rod 1
4
Hairpin cotter 1
Install the latch rod.
Bagger top 1
5
Bagger screen 1
Assemble the bagger top.
Bag frame
2
Bag assembly 2
Upper bagger tube 1
Pivot bracket (Model 79392 only)
2
Bolt (5/16 x 1 inch) (Model 79392 only)
4
6
Nut (5/16 inch) (Model 79392 only)
4
Install the bagger top.
7
No parts required
–
Install the blowout baf e (54in mower
deck only).
Cutof f baf e (Model 79390 only)
1
Carriage bolt (5/16 x 1-3/8 inches)
(Model 79393 only)
2
8
Flange nut (5/16 inch) (Model 79393
only)
2
Install the cutof f baf e (Models 79390,
79392, and 79393 only).
Chute
1
Knobs (Model 79393 only)
2
9
Flat washers (5/16 inch) (Model 79393
only)
2
Install the chute.
