Toro 79391 - Installing the Blowout Baffle (54 In Mower Deck Only); Installing the Cutoff Baffle (Models 79390, 79392, and 79393 Only); No Parts Required; Cutoff Baffle (Model 79390 Only)

7
Installing the Blowout
Bafe (54in Mower Deck
Only)
No Parts Required
Procedure
Secure the blowout baf e to the mower deck using 2
carriage bolts and 2 locknuts.
g028409
Figure 26
1. Locknuts 3. Bolts
2. Blowout baf e
8
Installing the Cutoff Bafe
(Models 79390, 79392, and
79393 Only)
Parts needed for this procedure:
1
Cutof f baf e (Model 79390 only)
2
Carriage bolt (5/16 x 1-3/8 inches) (Model 79393 only)
2
Flange nut (5/16 inch) (Model 79393 only)
For Model 79390 Only
1. Lift up the grass deector and locate the existing
cutof f baf e.
2. Remove the locknuts and bolt securing the
cutof f baf e to the underside of the mower deck.
Retain all of the fasteners.
g015220
Figure 27
1. Pivot rod
4. Nut (5/16 inch)
2. Bolt 5. Locknut
3. Cutof f baf e (existing)
3. Install the bagger-cutof f baf e to the underside
of the deck. Secure it with the fasteners that
were removed previously .
