Chapter 1: Introduction
DXi Quick Start Guide
• Integrated amperage meter to enhance internal diagnostics and trouble-
shooting.
• Up to nine simultaneous station-related operations (six valve and three MV)
• Cloud connect feature that enables cloud-based control via central software
and mobile phone app.
• Sentinel DXi systems feature Wireless Output Board Control for operating
stations using license-free radio with a range of several hundred feet.
• Laguna DXi systems feature robust Flowmax hardwire bus connectivity
between controllers.
Scheduling and Programming Features
• 16 conventional programs with up to 12 start times per program
• Exclusive DX series Individual Station Control (ISC™): Treat every active
station as an individual program
• Customizable scheduling calendar with up to 48 exclusion days
• Programmable MV and Station Delay
• Global water window (ISC & Manual can override)
• English, Spanish and French language settings
• Imperial (Standard) or Metric standard units of measure
Program Setup Options
Setup Menu Option Default
Time/Date 12:00:00am
Language English / Spanish English
Flow
Omit by Date
Communication
Current Checks
Firmware Update
Learn Flow / Current
About
Maintenance and Alarm Diagnostic Capabilities
• Flow monitoring. Overow, underow, unscheduled ow, and catastrophic
occurrence monitoring and reporting.
• Electrical alarm with station shutdown and program advance for station/s
over current, shorts, damaged wires, and/or faulty solenoids.
• Power outage restoration alarms.
• LED indication for station outputs.
• Electrical self diagnostic test to verify communication between the timing
mechanism (TM) and all modules.
