Toro Edge Series Service Manual

Reelmaster 7000- DHydraulic System Page 5 - 108
Rear Axle Motor
1. Rear axle motor
2. O- ring
3. Pinion gear
4. External snap ring (2)
5. O- ring
6. Hydraulic fitting
7. O- ring
8. 90
o
hydraulic fitting
9. Cap screw (2)
10. Flat washer (2)
11. O - ring
12. 90
o
hydraulic fitting
13. O- ring
14. O- ring
15. 90
o
hydraulic fitting
16. O- ring
17. Temperature sender with O- ring
Figure 66
FRONT
RIGHT
1
3
4
13
14
2
7
8
9
10
12
5
6
11
7
15
16
17
