Greensmaster 1000/1600 Traction and Reel Drive SystemsPage 4 – 1
Chapter 4
Traction and Reel Drive Systems
Table of Contents
SPECIFICATIONS 2. . . . . . . . . . . . . . . . . . . . . . . . . . . .
SPECIAL TOOLS 3. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Drum Bushing Tool Kit 3. . . . . . . . . . . . . . . . . . . . . . .
ADJUSTMENTS 4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Differential Belt Adjustment 4. . . . . . . . . . . . . . . . . . .
Drum Drive Belt Adjustment 5. . . . . . . . . . . . . . . . . .
Reel Drive Belt Adjustment 6. . . . . . . . . . . . . . . . . . .
Service/Park Brake Adjustment 7. . . . . . . . . . . . . . .
SERVICE AND REPAIRS 8. . . . . . . . . . . . . . . . . . . . . .
Reel Drive Assembly 8. . . . . . . . . . . . . . . . . . . . . . . .
Reel Drive Belt Replacement 9. . . . . . . . . . . . . . . . .
Reel Drive Idler Pulley and Bearing 9. . . . . . . . . . . .
Clutch Bearing 10. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Drum Drive Assembly 12. . . . . . . . . . . . . . . . . . . . . .
Drum Drive Belt Replacement 13. . . . . . . . . . . . . . .
Drum Drive Idler Pulley and Bearing 13. . . . . . . . . .
Differential Axle Pulley and Bearing 14. . . . . . . . . .
Drum Shaft Bearing 15. . . . . . . . . . . . . . . . . . . . . . . .
Drum Assembly with Bearings 16. . . . . . . . . . . . . . .
Drum Assembly with Bushings 18. . . . . . . . . . . . . . .
Counter Shaft Assembly 20. . . . . . . . . . . . . . . . . . . .
Brake Band Replacement 21. . . . . . . . . . . . . . . . . . .
Power Shaft Bearing 22. . . . . . . . . . . . . . . . . . . . . . .
Differential Axle Bearing
(Countershaft Housing) 23. . . . . . . . . . . . . . . . . . . . .
Differential Idler and Bearing 24. . . . . . . . . . . . . . . .
Differential Assembly and Pulley 25. . . . . . . . . . . . .
Differential Belt Replacement – Models 04051,
04052, and 04060 29. . . . . . . . . . . . . . . . . . . . . . .
Differential Belt Replacement – Model 04050 30. .
Lubrication 35. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Traction and Reel
Drive System
