Greensmaster 1000/1600Traction and Reel Drive Systems Page 4 – 2
Specifications
Item Description
Traction Drive Engine to countershaft drive has two ”A” section V–belts.
Countershaft to differential drive has 5 mm pitch timing belt.
Differential to drum drive has a 8 mm pitch timing belt.
Differential Peerless series 100
Brake Band drum
Traction Drum Dual cast aluminum, 7.5 inch (19.1 cm) diameter
Reel Clutch Jaw type
