Toro Greensmaster 1021 - Adjusting the Traction-Drum Position; Adjusting the Handle Height; Transporting the Machine to a Job Site; Transporting the Machine Using Transport Wheels

g275053
Figure13
1.Reel-speed-controlknob(showninthehigh-reel-speed
position)
Adjustingthe
Traction-DrumPosition
Thetractiondrumcanbeadjustedto2positions:
•LOWposition:Usethispositionformowingata
lowerheightofcut(e.g.,mowingagolf-course
green).
•HIGHposition:Usethispositionformowingata
higherheightofcut(e.g.,mowingagolf-course
teebox).
1.MovethekickstandtotheCUTTING-UNITSERVICE
position;refertoKickstand(page10).
2.Removetheshoulderbolts(Figure14)oneach
sideofthemachinethatsecurethedrumdrive
housingtothechassis.
g277026
Figure14
Leftsideofthemachineshown
1.Insertshoulderbolthere
fortheLOWposition.
3.Shoulderbolt
2.Insertshoulderbolthere
fortheHIGHposition.
3.Aligntheholesinthechassiswiththeholesin
thedrivehousing.
4.Usethepreviouslyremovedshoulderboltsto
securethedrivehousingtothechassis(Figure
14).
5.MovethekickstandtotheSTORAGEposition;
refertoKickstand(page10).
AdjustingtheHandle
Height
Usethehandle-heightadjustertoadjustthehandle
heighttoacomfortableoperatingposition;referto
Handle-HeightAdjuster(page10).
TransportingtheMachine
toaJobSite
TransportingtheMachineUsing
TransportWheels
Usethetransportwheelstotransportthemachinea
shorterdistance.
1.Installthetransportwheels;refertoInstalling
theTransportWheels(page19).
14
