Toro Greensmaster 1021 - Servicing the Spark Plug

Note:Ensurethatnodirtordebrisfromthe
air-cleanercoverfallintothebase.
4.Removethefoamandpaperelementsfromthe
base.
5.Removethefoamelementfromthepaper
element.
6.Inspectthefoamandpaperelements;replace
themiftheyaredamagedorexcessivelydirty.
g265999
Figure26
1.Wingnut
4.Paperlterelement
2.Air-cleanercover
5.Gasketandairduct
3.Foamelement
7.Cleanthepaperelementbytappingitgentlyto
removethedirt.
Note:Donottrytobrushdirtoffthepaper
element;brushingforcesthedirtintothebers.
Replacetheelementiftappingitfailstoremove
thedirt.
8.Cleanthefoamelementinwarm,soapywater
orinanonammablesolvent.
Note:Donotusegasolinetocleanthefoam
elementbecauseitcouldcreateariskofreor
explosion.
9.Rinseanddrythefoamelementthoroughly.
10.Wipedirtfromthebaseandthecoverwitha
moistrag.
Note:Ensurethatdirtanddebrisdonotenter
theairductleadingtothecarburetor.
11.Installtheair-cleanerelementsandensurethat
theyareproperlypositioned.Installthelower
wingnut.
12.Installthecoverandinstalltheupperwingnut
tosecureit.
ServicingtheSparkPlug
ServiceInterval:Every100hours/Every6months
(whichevercomesrst)
Every300hours/Yearly(whichevercomesrst)
UseanNGKBPR6ESsparkplugorequivalent.
1.Shutofftheengineandwaitforallmovingparts
tostop;refertoShuttingOfftheEngine(page
19).
2.Cleanaroundthesparkplug.
3.Removethesparkplugfromthecylinderhead.
Important:Replaceacracked,fouled,or
dirtysparkplug.Donotsandblast,scrape,
orcleantheelectrodesbecauseengine
damagecouldresultfromgritenteringthe
cylinder.
4.Setthegapontheplugto0.7to0.8mm(0.028
to0.031inch)
g000533
Figure27
1.Center-electrodeinsulator
3.Airgap
2.Sideelectrode
5.Carefullyinstallthesparkplugbyhand(toavoid
crossthreading)untilitishandtight.
6.Tightenthesparkpluganadditional1/2turnif
itisnew;otherwise,tightenitanadditional1/8
to1/4turn.
Important:Aloosesparkplugcanbecome
veryhotandcandamagetheengine;
overtighteningasparkplugmaydamagethe
threadsinthecylinderhead.
7.Connectthewiretothesparkplug.
25
