Toro Greensmaster 1021 - Removing the Cutting Unit

4.Slidethecutting-unit-drivecouplerontothe
transmissiondriveshaft(Figure34).
Thecouplershouldslideontothetransmission
driveshaftwithoutresistance.Ifthereis
resistance,ensurethatthereeldriveshaftand
thetransmissiondriveshaftarealigned.
Youcanadjustthereeldriveshaftpositionby
adjustingthereel-drive-assemblyposition:
A.LoosentheboltshowninFigure35.
g304660
Figure35
1.Reel-driveassembly2.Bolt
B.Rotatethereel-driveassemblysothatthe
reeldriveshaftisproperlyalignedwiththe
transmissiondriveshaft.
C.Tightentheboltthatyoupreviously
loosened.
Ifresistancecontinues,adjusttheengineand
transmissionalignment;refertotheService
Manual.
5.Installthegrassbasket.
RemovingtheCuttingUnit
1.MovethekickstandtotheCUTTING-UNIT-SERVICE
position;refertoKickstand(page10).
2.Removethegrassbasket(ifequipped).
3.Releasethecutting-unit-drivecouplerfromthe
transmissiondriveshaft(Figure36).
g304661
Figure36
1.Cutting-unit-drivecoupler2.Socket-headscrew
4.Removethesocket-headscrewsthatsecurethe
cuttingunittotheframe(Figure36).
5.Removethecuttingunitfromtheframe.
29
