Toro Greensmaster 1021 - Setup; Loose Parts; Adjusting and Installing the Cutting Unit

Setup
LooseParts
Usethechartbelowtoverifythatallpartshavebeenshipped.
ProcedureDescription
Qty.
Use
Cuttingunit(orderseparately;contact
yourauthorizedTorodistributor)
1
Coupler
1
1
Spring
1
Adjustandinstallthecuttingunittothe
machine.
Rightwheelshaft
1
2
Leftwheelshaft
1
Installthetransportwheelshafts(Model
04840only).
3
TransportWheelKit(orderseparately;
contactyourauthorizedTorodistributor)
1
Installthetransportwheels(optional).
4
Grassbasket
1Installthegrassbasket.
MediaandAdditionalParts
Description
Qty.
Use
Operator'sManual
1
EngineOwner'sManual
1
CerticateofCompliance
1
Readorviewtheitemsbeforeoperatingthemachine.
Note:Determinetheleftandrightsidesofthemachinefromthenormaloperatingposition.
1
AdjustingandInstallingthe
CuttingUnit
Partsneededforthisprocedure:
1
Cuttingunit(orderseparately;contactyourauthorized
Torodistributor)
1
Coupler
1
Spring
Procedure
1.Adjustthecuttingunittoyourdesiredsettings;
refertothecuttingunitOperator’sManual.
2.Installthecouplerandspringtothe
reel-drive-assemblyofthecuttingunit(Figure3).
g304658
Figure3
1.Coupler
3.Reel-driveassembly
2.Spring
3.Installthecuttingunittothemachine;referto
InstallingtheCuttingUnit(page28).
