InstallingtheGrassBasket
Partsneededforthisprocedure:
1
Grassbasket
Procedure
Graspthebasketbythetoplipandslideitontothe
basketmountingrods(Figure5).
g278331
Figure5
1.Grassbasket
2.Basketmountingrod
ProductOverview
g274957
Figure6
1.Grassbasket
4.Fueltank
2.Kickstand5.Transport-wheelaxle
3.Handle
6.Cuttingunit
