Toro Greensmaster 1021 - Changing the Engine Oil; Servicing the Air Cleaner

g266053
Figure24
1.Dipstick2.Drainplugandwasher
3.Removethedipstickbyrotatingit
counterclockwise.
4.Removethedipstickandwipetheendclean.
5.Insertthedipstickfullyintotheoil-lltube,but
donotthreaditin.
6.Removethedipstickandchecktheengine-oil
level(Figure25).
g019686
Figure25
1.Fillertube4.Lowerlimit
2.Dipstick5.Drainplug
3.Upperlimit
7.Iftheengine-oillevelisincorrect,addordrainoil
tocorrectthelevel;refertoChangingtheEngine
Oil(page24).
ChangingtheEngineOil
ServiceInterval:Aftertherst20hours/Aftertherst
month(whichevercomesrst)
Every100hours/Every6months(whichever
comesrst)
WARNING
Oilmaybehotaftertheenginehasbeenrun,
andcontactwithhotoilcancausesevere
personalinjury.
Avoidcontactingthehotengineoilwhenyou
drainit.
1.Shutofftheengineandwaitforallmovingparts
tostop;refertoShuttingOfftheEngine(page
19).
2.Placeapanunderthedrainplugtocatchtheoil.
3.Removethedrainplug,washer,anddipstick
(Figure24).
4.Positiontheenginesothattheoildrainsfrom
theengine.
5.Whentheoilhasdrainedcompletely,movethe
enginetoalevelpositionandinstallthedrain
plugandanewwasher.
Note:Disposeoftheusedoilatacertied
recyclingcenter.
6.Slowlypouroilintotheoil-llholeuntiltheoil
isatthecorrectlevel.
7.Ensurethattheoilisatthecorrectlevelonthe
dipstick;refertoCheckingtheEngine-OilLevel
(page23).
8.Threadthedipstickintotheoil-llhole.
9.Wipeupanyspilledoil.
10.Connectthewiretothesparkplug.
ServicingtheAirCleaner
ServiceInterval:Beforeeachuseordaily
Every50hours/Every3months(whichever
comesrst)
Every300hours/Yearly(whichevercomesrst)
Important:Donotoperatetheenginewithout
theairlterassembly;extremeenginedamage
willoccur.
1.Shutofftheengineandwaitforallmovingparts
tostop;refertoShuttingOfftheEngine(page
19).
2.Removethewingnutsecuringtheair-cleaner
cover(Figure26).
3.Removetheair-cleanercover.
