Toro Greensmaster 3120 - Pre-Maintenance Procedures; Removing the Seat Assembly; Raising the Machine

Pre-Maintenance
Procedures
RemovingtheSeat
Assembly
Note:Ifyouremovetheseatassemblyfrequently,
youcanreplacetherollpinwithanR-keypin(Part
No.3290-467).
Removetheseatassemblytoaccessthevalveblock
areaofthemachine.
1.Unlatchandraisetheseat,securingitwiththe
proprod.
2.Disconnectthe2wire-harnessconnectorsunder
theseat.
3.Lowertheseatandremovetherollpinsecuring
theseat-pivotrodtotheframe(Figure27).
g005497
Figure27
1.Rollpin
2.Seat-pivotrod
4.Slidetheseat-pivotrodtotheleft.
5.Movetheseatforwardandliftitoutofthe
machine.
6.Reversetheproceduretoinstalltheseat.
RaisingtheMachine
CAUTION
Ifthemachineisnotproperlysupported,it
couldfall,crushingyouorothers.
Beforeservicing,supportthemachinewith
jackstandsorblocksofwood.
Beforeraisingthemachine,lowerthecuttingunits.
Thejackingpointsareasfollows:
•Rightside—underthejackpadandadjacenttothe
ROPS-supportbracket(Figure28)
•Leftside—underthestep
•Rear—atthecasterfork
g005516
Figure28
1.Jackpad
28
