Toro Greensmaster
3150 - Marking the Outer Grass Baskets; Adding the Rear Ballast and Weight Kit; Installing the CE Guard Kit

5
MarkingtheOuterGrass
Baskets
NoPartsRequired
Procedure
Toassistinaligningthemachineforsuccessive
cuttingpasses,dothefollowingproceduretotheNo.
2andNo.3cuttingunitbaskets:
1.Measureinapproximately12.7cm(5inches)
fromtheouteredgeofeachbasket.
2.Eitherplaceastripofwhitetapeorpaintaline
ontoeachbasketparallelingtheouteredgeof
eachbasket(Figure9).
g005115
Figure9
1.Alignmentstrip
3.Cutgrassonright
2.Approximately12.7cm(5
inches)
4.Keepfocalspot1.8to3
m(6to10ft)aheadofthe
machine.
6
AddingtheRearBallast
andWeightKit
Partsneededforthisprocedure:
1
RearWeightKit(PartNo.100-6442)—purchase
separately
1
19.5kg(43lb)ofcalciumchloride(purchase
separately)
1
RearWeightKit(PartNo.99-1645)—purchase
separatelyifyouhavea3-WheelDriveKitinstalled
Procedure
ThismachinecomplieswiththeANSIB71.4-2017and
ENISO5395:2013Standardswhenyouequipitwith
theRearWeightKit(PartNo.100-6442)andadd19.5
kg(43lb)ofcalciumchlorideballasttotherearwheel.
Ifyouinstalla3-WheelDriveKit,usetheRearWeight
Kit(PartNo.99-1645)insteadofPartNo.100-6442.
Important:Ifapunctureoccursinatirewith
calciumchloride,removethemachinefromthe
turfareaasquicklyaspossible.Toprevent
possibledamagetotheturf,immediatelysoakthe
affectedareawithwater.
7
InstallingtheCEGuardKit
Partsneededforthisprocedure:
1
CEGuardKit―PartNo.04440(soldseparately)
Procedure
InstalltheCEguardkit;refertotheCEGuard
Kit―Greensmaster31502-WheelDriveTractionUnit
InstallationInstructions.
