Toro Greensmaster 3250-D - Mounting the Seat

MediaandAdditionalParts
Description
Qty.
Use
Operator'sManual
1
Reviewitbeforeoperatingthemachine.
Engineowner'smanual1
Useittoreferenceengineinformation.
DeclarationofConformity
1
Noiseratingcerticate
1
ForCEcompliance
Ignitionkeys2
Starttheengine.
Note:MountingfastenersfortheGreensmaster
3250-Dcuttingunitsareincludedwiththecuttingunits.
1
MountingtheSeat
Partsneededforthisprocedure:
1
Seat
4
Nut(5/16inch)
Procedure
Note:Mounttheseatslidesinthefrontsetof
mountingholestogainanadditional7.6cm(3inches)
intheforwardadjustment,orintherearmounting
holesforanadditional7.6cm(3inches)inthe
rearwardadjustment.
1.Removethelocknutssecuringtheseatslidesto
theshippingbasestraps.Discardthelocknuts.
2.Connectthewireharnesstotheseatswitch.
3.Securetheseatslidestotheseatsupportwith
thelocknuts(5/16inches)suppliedintheloose
parts(Figure3).
g008408
Figure3
1.Seatsupport2.Seatslide
10
