FuelSystem
Maintenance
ReplaceFuelFilter
ServiceInterval:Every600hours
1.Stoptheengine,removethekey,andwaitforall
movingpartstostopbeforeleavingtheoperating
position.
2.Allowthemachinetocooldown.
3.Loosenthehoseclampsandslidethemawayfrom
thelter(Figure52).
G010000
2
1
2
3
Figure52
1.Fuellter
3.Fuelline
2.Hoseclamp
4.Removethelterfromthefuellines.
5.Installanewltertothehosesandsecurethehose
clamps(Figure52).
ServicingtheFuelTank
Incertainconditions,gasolineisextremely
ammableandhighlyexplosive.Areor
explosionfromgasolinecanburnyouand
othersandcandamageproperty.
•Draingasolinefromthefueltankwhenthe
engineiscold.Dothisoutdoorsinanopen
area.Wipeupanygasolinethatspills.
•Neversmokewhendraininggasoline,and
stayawayfromanopenameorwherea
sparkmayignitethegasolinefumes.
1.Parkthemachineonalevelsurfacetoensurethat
thefueltanksdraincompletely.
2.Stoptheengineandremovethekey.
3.Loosenthehoseclampatthefuellterandslideit
upthefuellineawayfromthefuellter(Figure52).
4.Disconnectthefuellinefromthefuellter
(Figure52).
Note:Allowgasolinetodrainintoafuelcontainer
canordrainpan(Figure52).
Note:Thisisthebesttimetoinstallanewfuellter
becausethefueltankisempty.
5.Installthefuellineontothefuellter.Slidethehose
clampclosetothefuelltertosecurethefuelline
(Figure52).
