Schematics
TOWHITCHOPTION
TOWVECHICLE HYDRAULICS
LIFT
OFFSET
.042ORIFICE
PRESSURERELIEF1 100PSI
MINIMUM:4GPM MAXIMUM:12GPM PRESSURERELIEF:2000PSI
B
A
C2C1
C3 C4
S1
S3
S2
S4
A B
C1 C2
CB
RV2
RV1
1100PSI SETTING
500PSI CRACK
1500PSISETTING
G010006
Hydraulic(Rev.F)
45
