Figure45
1.Aircleanerhousing4.Aircleanercover
2.Primarylter5.Safetylter
3.Latch
3.Cleantheinsideoftheaircleanercoverwith
compressedair.
4.Gentlyslidetheprimarylteroutoftheaircleaner
housing(Figure45).
Note:Avoidknockingthelterintothesideofthe
housing.
5.Removethesafetylteronlyifyouintendtoreplace
it.
Important:Neverattempttocleanthesafety
lter.Ifthesafetylterisdirty,thentheprimary
lterisdamaged.Replacebothlters.
6.Inspecttheprimarylterfordamagebylookinginto
thelterwhileshiningabrightlightontheoutside
ofthelter.Holesinthelterwillappearasbright
spots.Ifthelterisdamaged,discardit.
ServicingthePrimaryAirFilter
ServiceInterval:Every200hours
Iftheprimaryairlterisdirty,bent,ordamaged,
replaceit.
Donotcleantheprimaryairlter.
ServicingtheSafetyAirFilter
ServiceInterval:Every600hours
Important:Neverattempttocleanthesafetyair
lter.Ifthesafetyairlterisdirty,thentheprimary
airlterisdamaged.Replacebothlters.
InstallingtheFilters
Important:Topreventenginedamage,always
operatetheenginewithbothairltersandcover
installed.
1.Ifinstallingnewlters,checkeachlterforshipping
damage.Donotuseadamagedlter.
2.Ifthesafetylterisbeingreplaced,carefullyslideit
intothelterbody(Figure45).
3.Carefullyslidetheprimarylteroverthesafetylter
(Figure45).
Note:Ensurethattheprimarylterisfullyseated
bypushingonitsouterrimwhileinstallingit.
Important:Donotpressonthesoftinsidearea
ofthelter.
4.Cleanthedirtejectionportlocatedintheremovable
cover.Removetherubberoutletvalvefromthe
cover,cleanthecavityandreplacetheoutletvalve.
5.Installtheaircleanercoverwiththesideindicatedas
upfacingupwardandsecurethelatches(Figure45).
6.ResettheindicatorFigure44)ifitshowsred.
ServicingtheEngineOil
Note:Changetheoilmorefrequentlywhenthe
operatingconditionsareextremelydustyorsandy.
OilType:Detergentoil(APIserviceSG,SH,SJor
higher)
CrankcaseCapacity:w/lter,67oz.(2l)
Viscosity:Seethetablebelow.
0
0
Figure46
CheckingtheEngineOilLevel
ServiceInterval:Beforeeachuseordaily
Note:Thebesttimetochecktheengineoiliswhenthe
engineiscoolbeforeithasbeenstartedfortheday.Ifit
hasalreadybeenrun,allowtheoiltodrainbackdownto
36
