thesumpforatleast10minutesbeforechecking.Ifthe
oillevelisatorbelowthe“add”markonthedipstick,
addoiltobringtheoilleveltothe“full”mark.DO
NOTOVERFILL.Iftheoillevelisbetweenthe“full”
and“add”marks,nooiladditionisrequired.
1.Parkthemachineonalevelsurface.
2.Turntheignitionkeytooff,andremovethekey.
3.Waitforallmovingpartstostopbeforeleavingthe
operatingposition.
4.Cleanaroundtheoildipstick(Figure47)sothatdirt
cannotfallintothellerholeanddamagetheengine.
Figure47
1.Oildipstick
2.Fillertube
5.Removetheoildipstickandwipetheendclean
(Figure47).
6.Slidetheoildipstickfullyintothellertube
(Figure47).
7.Pullthedipstickoutandlookattheend.Iftheoil
levelislow,slowlypouronlyenoughoilintotheller
tubetoraisetheleveltotheFULLmark.
Important:Donotoverllthecrankcasewith
oilandruntheengine;enginedamagecan
result.
ChangingtheOil
ServiceInterval:Aftertherst8hours
Every100hours
1.Starttheengineandletitrunveminutes.This
warmstheoilsoitdrainsbetter.
2.Parkthemachinesothatthedrainsideisslightly
lowerthantheoppositesidetoensuretheoildrains
completely.
3.Stoptheengine,removethekey,andwaitforall
movingpartstostopbeforeleavingtheoperating
position.
4.Placeapanbelowthedrainplug(Figure48).
5.Removetheoildrainplugallowingtheoiltodrain
intothepan.
6.Whenoilhasdrainedcompletely,installthedrain
plug.
Note:Disposeoftheusedoilatarecyclingcenter.
Figure48
1.Oildrainplug
7.Slowlypourapproximately80%ofthespeciedoil
intothellertube(Figure47).
8.Checktheoillevel;refertoCheckingtheEngineOil
Level.
9.SlowlyaddtheadditionaloiltobringittotheFull
mark.
ChangingtheOilFilter
ServiceInterval:Every200hours
Note:Changetheoilltermorefrequentlywhenthe
operatingconditionsareextremelydustyorsandy.
1.Draintheoilfromtheengine;refertoChangingthe
EngineOil.
2.Removetheoldlterandwipethelleradapter
gasketsurface(Figure49).
Figure49
1.Oillter
3.Adapter
2.Adaptergasket
3.Pournewoilinthroughthecenterholeofthelter.
Fillituptothebottomofthethreadsinside.
37
