ELECTRICAL
7-6
Toro TimeCutter SW/SWX Service Manual
7
BRAKE MODULE
1. Disconnect the negative (-) terminal from the
battery.
Brake Module Removal
2. Underneath the mower, remove the hair pin and
washer from the module on both sides. Remove
brake rods.
3. Remove the brake module cover screws.
4. Slide the cover back on the harness.
