Toro TimeCutter SW5425 - Pod; Fender Removal - LH; Pod; Fender Installation - LH

CHASSIS
3-5
Toro TimeCutter SW/SWX Service Manual
3
Pod / Fender Removal – LH
1. Raise seat and disconnect battery terminals.
2. Unscrew fuel cap. With a clean, long, needle nose
pliers, reach into fuel tank and grab fuel cap tether
base (D). Pull upward and ex tether base to remove
fuel cap from fuel tank assembly (Fig. 011).
Pod / Fender Installation – LH
1. Maneuver LH fender into position.
Note: The LH control lever must pass through the
LH fender during removal and installation.
2. Install the (3) screws (E) that secure the LH fender
to the frame and torque to specication – 7 ft-lbs.
(9 Nm).
3. Fully install the fuel cap tether base into fuel tank.
Install and tighten fuel cap.
4. Connect battery terminals, and lower seat.
(Fig. 012)
Fig. 011 PICT-1039
3. Remove the (3) screws (E) securing the LH fender to
the unit frame (Fig. 012).
4. Maneuver LH fender up and off frame.
Note: The LH control lever must pass through the
LH fender during removal and installation.
Fig. 012 PICT-1041
E
D
D
