g016484
1
2
Figure21
1.Blade-controlbarlock2.Blade-controlbar
2.Holdtheblade-controlbaragainstthehandle
(Figure22).
g016485
Figure22
DisengagingtheBlade
Releasetheblade-controlbar(Figure23).
G017596
Figure23
Important:Whenyoureleasetheblade-control
bar,thebladesshouldstopwithin3seconds.If
theydonotstopproperly,stopusingyourmachine
immediatelyandcontactanAuthorizedService
Dealer.
CheckingtheBlade-stop
SystemOperation
Beforeeachuse,checkthatthebladesstopwithin3
secondsofreleasingtheblade-controlbar.
UsingtheGrassBag
ServiceInterval:Beforeeachuseordaily
Youcanusethegrassbagtochecktheblade-stop
system.
1.Removetherear-dischargeplug.
2.Installtheemptygrassbagonthemachine.
3.Starttheengine.
4.Engagetheblades.
Note:Thebagshouldbegintoinate,indicating
thatthebladesarerotating.
5.Whilewatchingthebag,releasetheblade-controlbar.
Note:Ifthebagdoesnotdeatewithin3seconds
ofreleasingtheblade-controlbar,theblade-stop
systemmaybedeterioratingand,ifignored,could
resultinanunsafeoperatingcondition.Havethe
machineinspectedandservicedbyanAuthorized
ServiceDealer.
6.Stoptheengineandwaitforallmovingpartstostop.
NotUsingtheGrassBag
1.Movethemachineontoapavedsurfaceina
non-windyarea.
2.Setall4wheelstothe3-1/2inch(89mm)cutting
heightsetting.
3.Takeahalfsheetofnewspaperandcrumpleitintoa
ballsmallenoughtogounderthemachine(about3
inchesor75mmindiameter).
4.Placethenewspaperballabout5inches(13cm)in
frontofthemachine.
5.Starttheengine.
6.Engagetheblades.
7.Releasetheblade-controlbarandbegincountingout
3seconds.
8.Onthecountof3,pushthemachinequicklyforward
overthenewspaper.
9.Stoptheengineandwaitforallmovingpartstostop.
10.Gotothefrontofthemachineandcheckthe
newspaperball.
Note:Ifthenewspaperballdidnotgounderthe
machine,repeatsteps
4through10.
11.Ifthenewspaperisunravelledorshredded,the
bladesdidnotstopproperly,whichcouldresultinan
12

Toro TimeMaster 20199 Specifications

General

Engine Displacement	223cc
Cutting Width	30 inches
Starter	Recoil
Deck Material	Steel
Mulching Capability	Yes
Engine	Briggs & Stratton
Speed	Up to 4.5 mph
Warranty	3 years
Cutting Height	1.25 - 4.25" (3.2 - 10.8 cm)
Drive System	Personal Pace® Rear-Wheel Drive
