Toro TimeMaster 20199 User Manual

G016530
1
2
3
4
Figure45
1.Spindle(2)3.Blade(2)
2.Bladedriver(2)4.Bladebolt(2)
3.Inspectthepinsonthebladedriversforwearand
damage.
InstallingtheBlades
1.Installtherstbladesothatitishorizontal,along
withallmountinghardwareasshowninFigure45.
Note:Tightentheboltwithyourngers.
Important:Positionthecurvedendsofthe
bladestopointtowardthemachinehousing.
Besuretonesttheraisedareasoneachblade
driverwiththerecessesintheheadofits
correspondingspindle,andthepinsontheother
sideofeachbladedriverwiththeholesinits
correspondingblade.
2.Steadyeachbladewithaboardandturntheblade
boltclockwisewithatorquewrenchasshownin
Figure46;torquethebladeboltto60ft-lb(82N-m).
Important:Abolttorquedto60ft-lb(82N-m)
isverytight.Putyourweightbehindthewrench
andtightentheboltsecurely.Thisboltisvery
difculttoovertighten.
g016537
Figure46
3.Rotatetheinstalledblade1/4turnuntilitisvertical,
andinstalltheotherbladeinthesamemanneras
therst(refertostep1).
Note:Thebladesshouldbeperpendicular,forming
aninverted“T”asshownin
Figure47.
g01 6536
1
Figure47
1.Blade(2)
4.Tightenthesecondblade;refertostep2.
5.Rotatethebladesbyhandafull360°turntoensure
thattheydonottouch.
Note:Ifthebladestoucheachother,theyarenot
mountedcorrectly.Repeatsteps1through3,until
thebladesnolongertoucheachother.
23

Toro TimeMaster 20199 Specifications

General

Engine Displacement	223cc
Cutting Width	30 inches
Starter	Recoil
Deck Material	Steel
Mulching Capability	Yes
Engine	Briggs & Stratton
Speed	Up to 4.5 mph
Warranty	3 years
Cutting Height	1.25 - 4.25" (3.2 - 10.8 cm)
Drive System	Personal Pace® Rear-Wheel Drive
