Toro TimeMaster 20199 - Side-Discharging the Clippings

G016513
1
2
Figure26
1.Bagrod
2.Notch(2)
4.Lowerthereardeectoruntilitrestsonthegrassbag.
RemovingtheGrassBag
Toremovethebag,reversethestepsinInstallingthe
GrassBagabove.
Side-dischargingtheClippings
Usethesidedischargeforcuttingverytallgrass.
Ifthebagisonthemachine,removeitandinsert
therear-dischargeplug;referto
(page9)before
side-dischargingtheclippings.
Important:Ensurethattherear-dischargeplugis
inplacebeforeyourecycletheclippings(Figure24).
WARNING
Thebladeissharp;contactingthebladecanresult
inseriouspersonalinjury.
Stoptheengineandwaitforallmovingpartstostop
beforeleavingtheoperatingposition.
InstallingtheSide-dischargeChute
Withthechuteinyourrighthand:
1.Liftopentheside-dischargedeector(Figure27).
G017521
1
2
Figure27
1.Side-dischargedeector2.Side-dischargechute
2.Installtheside-dischargechuteasshownin
Figure27andFigure28,andclosethedeectoronto
thechute.
G017522
Figure28
RemovingtheSide-dischargeChute
Toremovetheside-dischargechute,reversethestepsin
InstallingtheSide-dischargeChuteabove.
14
