AdjustingtheSelf-propelDrive
Cable
Wheneveryouinstallanewself-propelcable,orif
theself-propeldriveisoutofadjustment,adjustthe
self-propel-drivecable.
1.Loosenthecablesupportnut(
Figure37).
Figure37
2.Pulldownthecablejacket(towardthemower)until
thereisnoslackinthecable(Figure38).
Figure38
3.Tightenthenutonthecablesupport.
ServicingtheBlade-drive
System
ServiceInterval:Every50hours
1.Removetheblade-drivesystemcover(Figure39).
G016491
1
2
Figure39
1.Bolts
2.Cover
2.Brushorblowoutdebrisfromtheinsideofthe
shieldandaroundalltheparts.
3.Holda0.010-inchfeelergauge,apieceofpaper,ora
notecardagainstthewallandslideitdownbehind
thebelttensionspring.
Note:Ifthereisavisiblegapbetweenthegauge
andthespring,tightentheadjustingboltandthenut
untilthepaperbarelyslidesfreelyinandoutofthe
gap(
Figure40).
g017221
2
1
3
4
5
6
Figure40
1.Belt-tensionspring4.Adjustingnut
2.Adjustingbolt5.Blade-drivebelt
3.Gap
6.Wall
20

Toro TimeMaster 20199 Specifications

General

Engine Displacement	223cc
Cutting Width	30 inches
Starter	Recoil
Deck Material	Steel
Mulching Capability	Yes
Engine	Briggs & Stratton
Speed	Up to 4.5 mph
Warranty	3 years
Cutting Height	1.25 - 4.25" (3.2 - 10.8 cm)
Drive System	Personal Pace® Rear-Wheel Drive
