Toro TimeMaster 20199 User Manual

ReplacingtheFuse
Electric-startmodelonly
Ifthebatterydoesnotchargeortheenginedoesnot
turnwiththeelectricstarter,thefusemaybeblown;
replaceitwitha40-ampplug-intypefuse.
Important:Youcannotstartthemachinewith
theelectricstarterorchargethebatteryunlessa
workingfuseisinstalled.
1.Openthesealedfuseholderandreplacethefuse
(
Figure35).
1
g016487
Figure35
1.Fuseholder
2.Closethecovertothefuseholder,andensurethatit
issealedtightly.
ReplacingtheBattery
Electric-startmodelonly
RemovingtheOldBattery
1.ContactanAuthorizedPartsDealertoobtaina
replacementbattery.
2.Removethebeltcover;refertostep
1of
ServicingtheBlade-driveSystem(page20).
3.Removetherear-dischargeplug.
4.Movethehandletotheverticalposition.
5.Removethe4smallboltsthatholdtherear-deector
andhandle-lockleverassemblyinplace.
6.Foldthehandleallthewayforward.
7.Removetherear-deectorandhandle-locklever
assembly(
Figure36).
G017523
1
Figure36
1.Rear-deectorandhandle-lockleverassembly
8.Removethecoverfromthebattery.
9.Disconnecttheleadsfromthebattery.
10.Removeandbatteryandrecycleit.
Note:Recyclethebatteryaccordingtoyourstate
andlocalregulations.
InstallingtheNewBattery
1.Cleanthebattery-holdingareaonthemower
housing.
2.Setthenewbatteryinplaceonthemowerhousing.
3.Connecttheleadstothenewbattery.
Note:Ensurethatyouconnecttheblack(negative)
wiretothenegative(-)terminalandthered(positive)
wiretothepositive(+)terminal.
4.Installthecoverontothebattery.
Note:Ensurethatthecovertsproperlyoverthe
wiringharness.
5.Installtherear-deectorandhandle-locklever
assemblyontothemachine.
6.Raisethehandletotheverticalposition.
7.Securetheshroudwiththe4smallboltsthatyou
removedinstep
5ofRemovingtheOldBattery.
8.Installtherear-dischargeplug.
9.Returnthehandletotheoperatingposition.
19

Toro TimeMaster 20199 Specifications

General

Engine Displacement	223cc
Cutting Width	30 inches
Starter	Recoil
Deck Material	Steel
Mulching Capability	Yes
Engine	Briggs & Stratton
Speed	Up to 4.5 mph
Warranty	3 years
Cutting Height	1.25 - 4.25" (3.2 - 10.8 cm)
Drive System	Personal Pace® Rear-Wheel Drive
