Toro TimeMaster 20199 - Assembling the Handle

104-7953
Electric-startmodelonly
1.Warning—readtheOperator'sManualforinformationonchargingthebattery;containslead;donotdiscard.
2.ReadtheOperator'sManual.
Setup
Important:Removeanddiscardtheprotective
plasticsheetthatcoverstheengine.
1
AssemblingtheHandle
NoPartsRequired
Procedure
WARNING
Assemblingandunfoldingthehandleimproperly
candamagethecables,causinganunsafeoperating
condition.
•Donotdamagethecableswhenunfoldingthe
handle.
•Ifacableisdamaged,contactanAuthorized
ServiceDealer.
1.Rotatetheupperhandlesothatitneststogether
withthelowerhandle(Figure3),andtightenboth
knobsonthehandletolocktheupperhandlein
place(Figure4).
1
G016547
2
Figure3
1.Upperhandle
2.Knob(2)
1
G016551
Figure4
1.Handle-locklever
2.Releasethehandle-locklever(Figure4).
3.Pullthehandlerearwardandlockitintoposition
(Figure4).
5
