CheckingtheEngineOilLevel
ServiceInterval:Beforeeachuseordaily
Max.ll:20oz.(0.59l),type:SAE30detergentoil
withanAPIserviceclassicationofSF,SG,SH,SJ,SL,
orhigher.
1.Movethemachinetoalevelsurface.
2.Removethedipstick(Figure12).
G017514
Figure12
3.Wipeoffthedipstickendwithacleancloth.
4.Insertthedipstickintotheoil-lltubeandscrewit
inuntilitstops.(Figure12).
5.Removethedipstickandreadtheoillevel;referto
Figure13.
Figure13
1.Theoillevelistoolow;
addoiltothecrankcase.
3.Theoilleveliscorrect.
2.Theoillevelistoohigh;
removeoilfromthe
crankcase.
•Iftheoillevelistoolow,addasmallamountof
oilslowlytotheoil-lltube,andthenrepeat
steps
3through5untiltheoilleveliscorrectas
showninFigure7.
•Iftheoillevelistoohigh,draintheexcess
oiluntilyouobtainthecorrectoillevelon
thedipstick;todraintheexcessoil,referto
ChangingtheEngineOil(page17).
Important:Iftheoillevelinthecrankcaseis
toolowortoohighandyouruntheengine,
youmaydamagetheengine.
6.Installthedipsticksecurelybyhand.
AdjustingtheCuttingHeight
WARNING
Adjustingthecuttingheightmaybringyouinto
contactwiththemovingblades,causingserious
injury.
•Stoptheengineandwaitforallmovingparts
tostop.
•Donotputyourngersunderthehousingwhen
adjustingthecuttingheight.
Adjustthecuttingheightasdesired;referto
Figure14andFigure15.
Note:Toraisethemachine,movethefrontandrear
cuttingheightleversforward;tolowerthemachine,
movethecuttingheightleversrearward.Setthefront
andrearwheelstothesameheightunlessspecial
circumstancesrequireotherwise;refertoCuttingGrass
andCuttingLeavesin
OperatingTips(page15).
1
2
3
4
5
6
7
G017634
Figure14
Frontcutting-heightlever
1.1inch(2.5cm)5.3inches(7.6cm))
2.1-1/2inches(3.8cm)6.3-1/2inches(8.9cm))
3.2inches(5.1cm)7.4inches(10.2cm)
4.2-1/2inches(6.4cm)
9

Toro TimeMaster 20199 Specifications

General

Engine Displacement	223cc
Cutting Width	30 inches
Starter	Recoil
Deck Material	Steel
Mulching Capability	Yes
Engine	Briggs & Stratton
Speed	Up to 4.5 mph
Warranty	3 years
Cutting Height	1.25 - 4.25" (3.2 - 10.8 cm)
Drive System	Personal Pace® Rear-Wheel Drive
