Toro TX 427 - Access Covers and Screens; Rear-Access Cover Operation; Side Screen Installation and Removal; Front Screen Removal Safety Caution

OpeningtheRear-AccessCover
1.Unscrewthe2handknobssecuringthe
rear-accesscovertothemachine(Figure25).
g004185
Figure25
1.Handknobs
2.Tilttherear-accesscoverdownandremoveitto
accesstheinternalcomponents(Figure25).
ClosingtheRear-AccessCover
1.Movetherear-accesscoverinplaceoverthe
backofthemachine;ensurethatthetabsline
upintheslots.
2.Pushtheaccesscoverforward,liningupthe
hand-knobscrewswiththethreadedholesin
themachine.
3.Screwthehandknobstighttosecurethe
rear-accesscoverinplace.
RemovingtheSideScreens
1.Openthehood.
2.Slidethesidescreens(Figure26)upandoutof
theslotsinthefrontscreenandframe.
g004186
Figure26
1.Sidescreen
InstallingtheSideScreens
Slidethesidescreensintoplaceintheslotsinthe
frontscreenandframe.
RemovingtheFrontScreen
CAUTION
Iftheenginehasbeenrunning,theheatshield
willbeveryhotandcouldburnyou.
Allowthemachinetocoolcompletelybefore
touchingtheheatshield.
1.Openthehoodandremovebothsidescreens.
2.Loosentheboltssecuringtheweights(Figure
27).
g013122
Figure27
1.Frontweight
4.Carriagebolts
2.Bolts5.Rearweight
3.Slopedplate
3.Removethecarriageboltsandnutssecuringthe
slopedplate(Figure27).
4.Lifttheslopedplateupandoffthemachine.
5.Removethe4boltssecuringthefrontscreento
theframe(Figure28).
