Auxiliary-HydraulicsControls
g411222
Figure11
1.Operateauxiliary
hydraulicsintheforward
direction.
2.Operateauxiliary
hydraulicsinthereverse
direction.
Auxiliary-HydraulicsLockPedal
Useyourrightfoottopresstheauxiliary-hydraulics
lockpedaltocontinuetheforwardorreverseowof
theauxiliaryhydraulicsandfreeyourhandforother
controls.
g357086
Figure12
1.Auxiliary-hydraulicslockpedal
Parking-BrakeLever
•Toengagetheparkingbrake,rotatetheleverto
left.
Note:Thetractionunitmayrollslightlybeforethe
brakesengageinthedrivesprocket.
•Toreleasethebrake,rotatethebrakelevertothe
right.
Note:Youmayneedtoadjustthetractioncontrol
toreleasethebrakepinsandrotatethelever.
g030721
Figure13
FuelGauge
Thisgaugemeasurestheamountoffuelinthefuel
tank(s).
