MessageDisplay
Engine-Coolant-TemperatureLight
Iftheenginecoolantbecomestoohot,thelighton
theleftofthedisplayashesandthehornsounds.If
thishappens,disengagetheauxiliaryhydraulicsand
letthemachinerunathighidletoallowthecooling
systemtocoolthemachine.Checkthecoolantlevel
whentheenginehasfullycooled.
Important:Donotshutofftheengine,asthis
maycausethemachinetooverheat.
g029201
Figure14
Engine-Oil-PressureLight
Iftheengine-oil-pressurebecomestoolow,thelight
ontheleftofthedisplayilluminatessteadily.Ifthis
happens,shutofftheengineimmediatelyandcheck
theoillevel.Ifitislow,addoilandlookforpossible
leaks.
g029665
Figure15
Glow-PlugLight
Thelightontherightasheswhiletheglowplugsare
chargedandwarmingtheengine.
g029199
Figure16
Battery-ChargeLight
Ifthebatterychargebecomestoolow,thelighton
therightilluminatessteadily.Ifthishappens,shutoff
theengineandchargeorreplacethebattery.Refer
toServicingtheBattery(page37).
g029207
Figure17
HourMeter
Thehourmeterdisplaysthenumberofhoursof
operationthathavebeenloggedonthetractionunit
andthefollowingindicators:
•Enginestart—displayswhenyoustarttheengine
g029974
Figure18
•Parkingbrake—displayswhenyoudisengagethe
parkingbrake
g029251
Figure19
•Tractionneutral—displayswhenthetraction
controlisintheNEUTRALposition
g029211
Figure20
•Auxiliaryleverneutral—displayswhentheauxiliary
leverisintheNEUTRALposition
g029975
Figure21
