Toro TX 700 - Pre-Maintenance Procedures; Using the Cylinder Locks; Accessing Internal Components

Pre-Maintenance
Procedures
UsingtheCylinderLocks
WARNING
Theloaderarmsmaylowerwhenintheraised
position,crushinganyoneunderthem.
Installthecylinderlock(s)beforeperforming
maintenancethatrequiresraisedloaderarms.
InstallingtheCylinderLocks
1.Removetheattachment.
2.Raisetheloaderarmstothefullyraisedposition.
3.Shutofftheengineandremovethekey.
4.Removethe2pinssecuringthecylinderlockto
thepostsonthesideofthemachine.
5.Slidethecylinderlockoverthelift-cylinderrod
(Figure32).
g365284
Figure32
1.Cylinderlock3.Pin(2)
2.Lift-cylinderrod
6.Repeatstep4and5fortheothersideofthe
machine.
7.Slowlylowertheloaderarmsuntilthecylinder
lockscontactthecylinderbodiesandrodends.
RemovingandStoringthe
CylinderLocks
Important:Removethecylinderlocksfromthe
rodsandfullysecuretheminthestorageposition
beforeoperatingthemachine.
1.Starttheengine.
2.Raisetheloaderarmstothefullyraisedposition.
3.Shutofftheengineandremovethekey.
4.Removethepinssecuringthecylinderlocks.
5.Placethecylinderlocksonthepostsonthe
sidesofthemachineandsecurewiththepins.
6.Lowertheloaderarms.
AccessingInternal
Components
WARNING
Openingorremovingcovers,hoods,and
screenswhiletheengineisrunningcould
allowyoutocontactmovingparts,seriously
injuringyou.
Beforeopeninganyofthecovers,hoods,and
screens,shutofftheengine,removethekey
fromthekeyswitch,andallowtheengineto
cool.
OpeningtheHood
1.Usethelatchkeytounlockthelever.
g365296
Figure33
2.Usethelevertoliftopenthehood
3.Securetheproprod.
28
