Toro TX 700 - Replacing the Water Separator Filter; Replacing the In-Line Fuel Filter; Checking the Fuel Lines and Connections

ReplacingtheWater
SeparatorFilter
ServiceInterval:Every500hours
1.Parkthemachineonalevelsurface,engagethe
parkingbrake,andlowertheloaderarms.
2.Shutofftheengineandremovethekey.
3.Openthehood.
4.Cleantheareawheretheltercanistermounts.
g365572
Figure46
1.Waterseparator
5.Removetheltercanisterandcleanthe
mountingsurface.
6.Lubricatethegasketonthenewltercanister
withcleanoil.
7.Fillthecanisterwithfuel.
8.Installtheltercanisterbyhanduntilthegasket
contactsthemountingsurface,thenrotateitan
additional1/2turn.
9.Closethehood.
ReplacingtheIn-LineFuel
Filter
ServiceInterval:Every500hours
1.Parkthemachineonalevelsurface,engagethe
parkingbrake,andlowertheloaderarms.
2.Shutofftheengineandremovethekey.
3.Removetherearcover;refertoRemovingthe
RearCover(page29).
4.Replacethelterasshown.
Note:Ensurethatthemarkingsonthelter
followthefuelowdirection.
g033082
Figure47
CheckingtheFuelLines
andConnections
ServiceInterval:Every400hours/Yearly(whichever
comesrst)
Inspectthefuellinesandconnectionsfordeterioration,
damage,orlooseconnections.Tightenanyloose
connectionsandcontactyourAuthorizedService
Dealerforassistanceinxingdamagedfuellines.
