ServicingtheBattery
ServiceInterval:Every50hours
RemovingtheBattery
WARNING
Incorrectbatterycableroutingcoulddamage
themachineandcables,causingsparks.
Sparkscancausethebatterygassesto
explode,resultinginpersonalinjury.
Alwaysdisconnectthenegative(black)
batterycablebeforedisconnectingthe
positive(red)cable.
1.Parkthemachineonalevelsurfaceandengage
theparkingbrake.
2.Raisetheloaderarmsandsecurethemwiththe
cylinderlocks.
3.Shutofftheengineandremovethekey.
4.Disconnectthenegative(black)groundcable
fromthebatterypost.Retainthefasteners.
g365667
Figure49
1.Positivecable4.Negativecable
2.Wingnutandrod(2)
5.Battery
3.Strap
5.Slidetherubbercoveroffthepositive(red)
cable.
6.Disconnectthepositive(red)cablefromthe
batterypost.Retainthefasteners.
7.Removethewingnuts,rods,andstrap.
8.Removethebattery.
ChargingtheBattery
WARNING
Chargingthebatteryproducesgassesthat
canexplode.
Neversmokenearthebatteryandkeepsparks
andamesawayfrombattery.
Important:Alwayskeepthebatteryfullycharged
(1.265specicgravity).Thisisespecially
importanttopreventbatterydamagewhenthe
temperatureisbelow0°C(32°F).
1.Removethebatteryfromthemachine;referto
RemovingtheBattery(page37).
2.Chargethebatteryfor4to8hoursatarateof3
to4A.Donotoverchargethebattery.
g003792
Figure50
1.Positivebatterypost
3.Red(+)chargerlead
2.Negativebatterypost
4.Black(-)chargerlead
3.Whenthebatteryisfullycharged,unplug
thechargerfromtheelectricaloutlet,then
disconnectthechargerleadsfromthebattery
posts.
