CleaningtheBattery
Note:Keeptheterminalsandtheentirebatterycase
clean,tohelpextendbatterylife.
1.Parkthemachineonalevelsurface,engage
theparkingbrake(ifequipped),andlowerthe
loaderarms.
2.Shutofftheengineandremovethekey.
3.Removethebatteryfromthemachine;
RemovingtheBattery(page37).
4.Washtheentirecasewithasolutionofbaking
sodaandwater.
5.Rinsethebatterywithclearwater.
6.Coatthebatterypostsandcableconnectorswith
Grafo112X(skin-over)grease(T oroPartNo.
505-47)orpetroleumjellytopreventcorrosion.
7.Installthebattery;refertoInstallingtheBattery
(page38).
InstallingtheBattery
WARNING
Incorrectbatterycableroutingcoulddamage
themachineandcables,causingsparks.
Sparkscancausethebatterygassesto
explode,resultinginpersonalinjury.
Alwaysconnectthepositive(red)battery
cablebeforeconnectingthenegative(black)
cable.
1.Placethebatteryonthebatterytrayandsecure
itwiththestrap,wingnuts,androds.
g365667
Figure51
1.Positivecable4.Negativecable
2.Wingnutandrod(2)
5.Battery
3.Strap
2.Usingthefastenerspreviouslyremoved,install
thepositive(red)batterycabletothepositive
(+)batteryterminal.
3.Slidetheredterminalbootontothepositive
batterypost.
4.Usingthefastenerspreviouslyremoved,install
thenegative(black)batterycabletothenegative
(-)batteryterminal.
5.Closethehood.
ServicingaReplacementBattery
Theoriginalbatteryismaintenance-freeanddoesnot
requireservice.Forservicingareplacementbattery,
refertothebatterymanufacturer’sinstructions.
Jump-StartingtheMachine
WARNING
Jump-startingthebatterycanproducegasses
thatcanexplode.
Donotsmokenearthebattery,andkeep
sparksandamesawayfrombattery.
1.Openthehood.
2.Checkandcleancorrosionfromthebattery
terminalsbeforejump-starting.Ensurethatthe
connectionsaretight.
CAUTION
Corrosionorlooseconnectionscan
causeunwantedelectricalvoltagespikes
atanytimeduringthejump-starting
procedure.
Donotattempttojump-startthemachine
withlooseorcorrodedbatteryterminals,
ordamagetotheenginemayoccur.
DANGER
Jump-startingaweakbatterythatis
crackedorfrozenorhasalowelectrolyte
leveloranopen/shortedbatterycellcan
causeanexplosion,resultinginserious
personalinjury.
Donotjump-startaweakbatteryifthese
conditionsexist.
3.Makesurethattheboosterbatteryisagood
andfullychargedlead-acidbatteryat12.6Vor
greater.
38
