g192347

Figure34

1.Spindle

2.Hubandrotorassembly

7.Wipecleanthespindlewitharag.

8.Repeatsteps1through7tothehubandrotorat

theothersideofthemachine.

GreasingtheWheelBearings

1.Removetheoutboardbearingandbearingrace

fromthehub(Figure35).

g033050

Figure35

1.Seal4.Bearingcavity(hub)

2.Inboardbearing

5.Outboard-bearingrace

3.Inboard-bearingrace

6.Outboardbearing

2.Removetheseal,inboardbearingfromthehub

(Figure35).

3.Wipecleanthesealandcheckforwearand

damage.

Note:Donotusecleaningsolventtocleanthe

seal.Replacethesealifitiswornordamaged.

4.Cleanthebearingsandraces,andcheckthese

partsforwearanddamage.

Note:Replaceallwornordamagedparts.

Ensurethatthebearingsandracesareclean

anddry.

5.Cleanthecavityofthehubofallgrease,dirt,

anddebris(Figure35).

6.Packthebearingswiththespeciedgrease.

7.Fillthecavityofhub50to80%fullofthe

speciedgrease(Figure35).

8.Assembletheinboardbearingontotheraceat

theinboardsideofthehubandinstalltheseal

(Figure35).

9.Repeatsteps1through8tothebearingsforthe

otherhub.
