ReplacingtheFuses

ForCarburetorModels

Thereare4fusesintheelectricalsystem;theother

slotsareopenforoptions.Theyarelocatedbeneath

theseatassembly(Figure51).

Horn30A

Mainpower15A

Headlights10A

USBpowerpoint/options

10A

Optionalliftkit—open

15A

g277715

Figure51

1.Fuseblock

ForEFIModels

Thereare5fusesintheelectricalsystem;theother

slotsareopenforoptions.Theyarelocatedbeneath

theseatassembly(Figure52).

Horn30A

Mainpower15A

Headlights10A

USBpowerpoint/options

10A

Fuel10A

Optionalliftkit—open

15A

g277716

Figure52

1.Fuseblock
