Workman GTX Gasoline
Electrical Drawings
Page 7 − 2
Electrical Drawing Designations
The following abbreviations are used for wire harness
colors on the electrical schematics and wire harness
drawings in this chapter.
ABBREVIATION
COLOR
BK BLACK
BR or BN BROWN
BU BLUE
GN GREEN
GY GRAY
OR ORANGE
PK PINK
R or RD RED
T or TN TAN
VIO VIOLET
W or WH WHITE
Y or YE YELLOW
Numerous harness wires used on Workman GTX
vehicles include a line with an alternate color. These
wires are identified with the wire color and line color with
either a / or _ separating the color abbreviations listed
above (e.g. R/BK is a red wire with a black line, OR_BK
is an orange wire with a black line).
NOTE: The wire harness diagram in this chapter identi-
fies both the wire color and the wire gauge. For example,
16 BK on a harness diagram identifies a 16 gauge wire
that has a black insulator.
NOTE: A splice used in a wire harness will be identified
on the wire harness diagram by SP. The manufacturing
number of the splice is also identified on the wire har-
ness diagram (e.g. SP01 is splice number 1).
