Workman GTX Gasoline Gasoline EnginePage 3 - 13
Figure 13
1. Supply hose fitting lock
(locked - down)
2. Supply hose fitting lock
(unlocked - up)
3. Supply hose fitting tab
1
2
3
3
LOCKED
UNLOCKED
