Toro Workman - Key Switch and Choke Control; Gear-Shift Lever and Indicator

KeySwitch
Thekeyswitchislocatedatthelower,rightcornerof
thedashpanel(Figure6).
Thekeyswitchhas3positions:OFF,ON,andSTART.
Thereare2modesofstartingthemachine;referto
StartingtheEngine(page22).
Parking-BrakeLever
Theparking-brakeleverislocatedonthecontrol
panel(Figure6).
Wheneveryoushutofftheengine,engagetheparking
braketopreventthemachinefromaccidentally
moving.Ifthemachineisparkedonasteepgrade,
ensurethatyouengagetheparkingbrake.
Toengagetheparkingbrake,pulltheparking-brake
levertowardyou(Figure7).
g033923
Figure7
1.Parking-brakelever
Todisengagetheparkingbrake,pushdownthe
buttonontopoftheparking-brakelever,pullthe
parking-brakelevertowardyoutoreleasepressure,
andthenpushtheparking-brakeleverforward(Figure
8).
g033924
Figure8
1.Parking-brakelever
ChokeControl
Thechokecontrolislocatedonthecontrolpanel.Use
thechoketohelpstartacoldenginebypullingthe
chokecontroloutward(Figure6).Aftertheengine
starts,adjustthechoketokeeptheenginerunning
smoothly.Astheenginewarmsup,pushinthechoke
controltotheOFFposition.
Gear-ShiftLeverandGear-Shift
Indicator
Thegear-shiftlevercanbesetto3positionson
thegear-shiftindicator:FORWARD,REVERSE,and
NEUTRAL(Figure9).
Note:Theenginestartsandrunsinanyofthe3
positions.
FromtheNEUTRALposition,youcanmovethe
gear-shiftleverlefttotheFORWARDpositionorright
totheREVERSEposition(Figure9).
Important:Alwaysstopthemachinebefore
changinggears.
g033922
Figure9
1.Gear-shiftindicator2.Gear-shiftlever
HornButton
InternationalModelsOnly
Thehornbuttonislocatedonthecontrolpanel(Figure
6).Pressthehornbuttontosoundthehorn.
