2GettingStartedToshibaB‐FV4TOwner’ sManual

19

2.4LoadingRibbon

Ribbonsareonlyrequiredforthermaltransferprinting.Youcanuseawax,wax ‐resin

orresinribbon.Thetypeoftheribbonandthemediashouldmatchtoeachotherto

gettheproperprintquality.Theribbonneedstobewiderthanorequaltothemedia

toprotecttheprintheadfromwear.

2.4.1  PreparingRibbon

Removethewrappingandtheprotectivefilmoftheribbon.Youwillfindtwopairsof

ribbon cores in the printer package. One of them is for 0.5‐inch inner diameter

ribbon andtheother isfor1‐inch. Installtheapplicablepair intotheribbon supply

rollandtake‐uproll.



Questions and Answers:

Need help?

Do you have a question about the Toshiba B-FV4T-GS12-QM-R and is the answer not in the manual?

Toshiba B-FV4T-GS12-QM-R Specifications

General

Printer Type	Thermal Transfer / Direct Thermal
Print Resolution	203 dpi (8 dots/mm)
Ribbon Width	Up to 110 mm
Ribbon Length	300 m
Processor	32-bit RISC
Flash Memory	8 MB
SDRAM	32 MB
Print Width	104 mm
Media Width	25.4 mm to 114 mm
Connectivity	USB, Serial, Ethernet
Memory	8 MB Flash, 32 MB SDRAM
Operating Temperature	5 to 40 °C
Media Thickness	0.06 to 0.25 mm
Media Roll Diameter	127 mm (5")
Supported Barcode Types	Code 39, Code 128, PDF417, QR Code
Power Supply	AC 100-240V, 50/60 Hz
