Toshiba B-FV4T-GS12-QM-R User Manual

B‐FV700‐BLTH‐QM‐R
‐40‐
6.2MediaandRibbon
Properties Description
MediaSize ContinuousMode
Length:8~997mm(including liner10~999mm)
Width:22.4~115mm(includingliner25.4~118mm)
Tear‐OffMode
Length:8~997mm(including liner10~999mm)
Width:22.4~115mm(includingliner25.4~118mm)
Peel‐OffMode
Length:23.4~150.4mm(includingliner25.4~152.4mm)
Width:22.4~115mm(includingliner25.4~118mm)
CutMode
Length:19.4~993mm(includingliner25.4~999mm)
Width:22.4~115mm(includingliner25.4~118mm)
MaxRollDiameterSize:127mm(5inches)
Max Roll Diameter Sizefor External Media Stand: 216 mm (8.5
inches)
MediaType ThermalTransferLabel
ThermalTransferTag
DirectThermalLabel
DirectThermalTag
RollPaper(InsideWoundorOutsideWound)
FanfoldPaper
RibbonSize Length:100m(φCoreSize:0.5inch),Max300m(φCoreSize:1
inch)
Width:40~110mm
RibbonType Wax,Wax‐Resin,Resin
CoatedSideInorCoatedSideOut

Toshiba B-FV4T-GS12-QM-R Specifications

General

Printer Type	Thermal Transfer / Direct Thermal
Print Resolution	203 dpi (8 dots/mm)
Ribbon Width	Up to 110 mm
Ribbon Length	300 m
Processor	32-bit RISC
Flash Memory	8 MB
SDRAM	32 MB
Print Width	104 mm
Media Width	25.4 mm to 114 mm
Connectivity	USB, Serial, Ethernet
Memory	8 MB Flash, 32 MB SDRAM
Operating Temperature	5 to 40 °C
Media Thickness	0.06 to 0.25 mm
Media Roll Diameter	127 mm (5")
Supported Barcode Types	Code 39, Code 128, PDF417, QR Code
Power Supply	AC 100-240V, 50/60 Hz
