9. Attach the freezer door on the bottom hinge,
then attach the center left hinge to the left side
of the refrigerator.
10.Remove the F door upper cover, install the
upper hinge sleeve and door signal line to the
other side
12. Put the refrigerator door onto the center left
hinge, then attach the top left hinge to the top
of refrigerator. Connect the signal wire terminals
with the door and box body. Connect the signal
wire terminals in the right terminal block.
Cover the hinge with the top left hinge cover
and cover the screw holes on the right side of
the top with the cover plate you previously
removed.
