1.TROUBLESHOOTING FOR THE HARDWARE
Clearing a Paper Misfeed 17
1 TROUBLESHOOTING FOR THE HARDWARE
If paper misfeeds occur frequently
The following are the common causes of paper misfeeds. If the problem persists, check for the following
situations.
y An unsuitable original is placed on the Reversing Automatic Document Feeder.
y Unavailable paper with the equipment is used.
y Paper sizes are not consistent between the size in a drawer or the bypass tray and the size registered in
the equipment.
y All the misfed paper has not been removed.
y There is too much of a gap between the paper and the side or end guide in the drawer.
y The amount of paper placed in a drawer exceeds the limit indicated on the side guide of the drawer.
Paper misfeed in the Reversing Automatic Document Feeder (Lower)
1
Open the Reversing Automatic Document Feeder.
2
Lower the green lever, open the reverse cover and
remove the original.
3
Close the Reversing Automatic Document Feeder.
2
1
1
To Next Page
