1 TROUBLESHOOTING FOR THE HARDWARE

20 Clearing a Paper Misfeed

 Paper misfeed in the Large Capacity Feeder

 Paper misfeed in the Paper Feed Pedestal

If the paper is misfed on the cover side, remove it as shown in

the figure on the right.

Open the feeder cover of the Large Capacity Feeder

on the right.

Remove the misfed paper and close the feeder cover.

Open the feeder cover of the Paper Feed Pedestal on

the right.
