1 TROUBLESHOOTING FOR THE HARDWARE

44 Clearing a Staple Jam

Lift the shutter knob while pulling the green lever

downward.

Remove the stale sheet left.

Do not touch the stapling area.

The actual needle point could cause you personal injury.

Push the shutter knob down and return it to its

original position.

Fit the staple cartridge.

Insert the cartridge until it is caught by the latch of the staple

cartridge and is fixed with a click.

Close the left cover of the finisher.
