Toshiba e-STUDIO2050C - Cleaning the Hole Punch Dust bin; Inner Finisher Hole Punch Unit

1 TROUBLESHOOTING FOR THE HARDWARE
62 Cleaning the Hole Punch Dust Bin
Cleaning the Hole Punch Dust Bin
When the hole punch dust bin becomes full, dispose of the paper punchings following the procedure below.
 Inner Finisher Hole Punch Unit
1
Lift up the control panel and then open the front cover
of the finisher.
2
While holding the green lever, move the finisher to the
left until it stops.
3
Open the Hole Punch Unit while pushing the green
lever.
4
After moving the hole punch dust bin to the left, pull it
toward you.
2
1
2
1
2
1
