Example Table Excerpt:
Register Function / Title Bank Mask Adjustment Range Multiplier
26
MAXIMUM OUTPUT
FREQUENCY (∗
∗∗
∗)
0 / 1 FFFF
0BB8 ∼ 9C40 (30.00∼400.00)
0.01
27
BASE FREQUENCY #1
0 / 1 FFFF
09C4 ∼ 9C40 (25.00∼400.00)
0.01
28
BASE FREQUENCY
VOLTAGE SELECT (∗
∗∗
∗)
0 / 1 0030 0000: Input voltage level (0)
0020: Automatic setting (1)
0030: Stationary setting (2)
29
MAXIMUM OUTPUT
VOLTAGE #1
0 / 1 FFFF
0000 ∼ 0258 (0 ∼ 600)
1
2A
REVERSE OPERATION
DISABLE SELECT
0 / 1 0020 0000: Reverse allowed (0)
0020: Reverse not allowed (1)
Other Programming Register Notes:
•= All register numbers indicated are in hexadecimal notation (for example, 29 hex =
41 decimal). Occasionally, hexadecimal notation in this document may also take
the form of a number beginning with “0x”.
•= Throughout this document, the abbreviations "LL", "UL", and "Fmax" will stand for
LOWER LIMIT FREQUENCY, UPPER LIMIT FREQUENCY, and MAXIMUM
OUTPUT FREQUENCY, respectively.
•= Reading from or writing to registers marked as "Reserved" will generate an
“invalid register” error (error code 0x0003)
•= Certain parameter registers cannot be written to while the inverter is running.
These registers will be indicated by the character (
∗
∗∗
∗). If an attempt is made to
write to these registers while the inverter is running, a “cannot execute” error
(error code 0x0001) will be generated.
•= The parameter register data for all read/write registers with Bank information
listed as 0/1 will be retrieved from bank 0 (RAM) during reads and will be written
to both banks 0 and 1 (RAM and EEPROM) during writes.
•= All parameters in GROUP:COMMUNICATION SETTING PARAMETERS (section
11.2.10) are retrieved by the drive from non-volatile memory upon inverter
initialization only. When any of these registers are modified, therefore, the drive
must be reset for the changed values to take effect.
•= If the COMMAND MODE SELECTION or FREQUENCY MODE SELECTION
parameters are changed while the drive is running, the change will not take effect
until the next time the drive is stopped.
