11.2.13 GROUP:MOTOR RATING PARAMETERS
GROUP:MOTOR RATING PARAMETERSGROUP:MOTOR RATING PARAMETERS
GROUP:MOTOR RATING PARAMETERS
Register Function / Title Bank Mask Adjustment Range Multiplier
242
NUMBER OF MOTOR POLES
0 / 1 00FF 0001: (2)
0002: (4)
0003: (6)
0004: (8)
0005: (10)
0006: (12)
0007: (14)
0008: (16)
2
243
MOTOR RATED CAPACITY
0 / 1 FFFF
0001 ∼ 270F (0.1 ∼ 999.9)
0.1
244
MOTOR TYPE
0 / 1 0030 0000:Toshiba EQPIII motor (0)
0010:Toshiba STD motor (1)
0020:Other (2)

245 2
MOTOR RATED
VOLTAGE
(230 / 460v units)
0 / 1 00FF
0012 ∼ 0078 (90 ∼ 600)
5
246 (575v units)
001A ∼ 00AC (130 ∼ 860)
247
MOTOR RATED
FREQUENCY
0 / 1 00FF
0000 ∼ 00C8 (0 ∼ 400)
2
248
MOTOR RATED RPM
0 / 1 FFFF
0000 ∼ 270F (0 ∼ 9999)
1
249
AUTO-TUNING ENABLE
0 0008 0000: Auto-tuning disabled (0)
0008: Auto-tuning enabled (1)

24A
LOAD MOMENT OF
INERTIA
0 / 1 00C0 0000: Small (0)
0040: Medium (1)
0080: Large (2)
00C0: Very large (3)

